Model |
CS-H3c-R100-1K2WF |
Image Sensor |
1/2.7” Progressive Scan CMOS |
Minimum Illumination |
0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
IR Night Vision Distance |
Up to 98 ft / 30 m |
Shutter Speed |
Self-adaptive shutter |
Lens |
4mm @ F2.0, 82° (Horizontal), 98° (Diagonal) |
Lens Mount |
M12 |
DNR |
3D DNR |
WDR |
Digital WDR |
Day/Night Switch |
IR-Cut filter with auto-switching |
Max. Resolution |
1080p (1920 × 1080) |
Frame Rate |
Max 30fps; Self-Adaptive |
Video Compression |
H.265 / H.264 |
Video Bit Rate |
Full HD / HD / Standard (Adaptive) |
Audio Bit Rate |
Self-Adaptive |
Max. Bitrate |
1 Mbps |
Wi-Fi Standard |
IEEE802.11b/g/n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
20 MHz |
Wi-Fi Transmission Rates |
11b: 11Mbps, 11g: 54Mbps, 11n: 144Mbps |
Wi-Fi Pairing |
AP Pairing |
Protocols |
EZVIZ Cloud Proprietary Protocol |
Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
Dimensions |
72 × 72 × 157 mm (2.83 × 2.83 × 5.98 in) |
Package Dimensions |
227 × 100 × 92 mm (8.94 × 3.94 × 3.62 in) |
Weight |
Net: 250 g (8.82 oz) / Packaged: 447 g (15.77 oz) |
IP Grade |
IP67 (Weatherproof) |
Operating Conditions |
-30°C to 50°C (-22°F to 122°F), Humidity ≤95% (non-condensing) |
Detection |
AI-Powered Human Shape Detection, Motion Detection |
Alert Area |
Supports Customized Detection Zone |
Integration |
Alexa, Google Assistant, IFTTT |
General Functions |
Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
Local Storage |
microSD card (Up to 512 GB) |
Cloud Storage |
EZVIZ CloudPlay (Subscription required) |
Power Supply |
DC 12V / 1A |
Power Consumption |
Max. 6W |
In the Box |
H3c Camera, Drill Template, Screw Kit, Waterproof Kit, Power Adapter, Regulatory Info, Quick Start Guide |
Certifications |
CE, FCC, UKCA, UL, WEEE, RoHS, REACH |
