- High-definition 2MP resolution for capturing clear and detailed images.
- Smart Hybrid Light technology delivers vibrant color images during the day and sharp black-and-white images at night.
- Automatic light adaptation ensures excellent image quality in all lighting conditions.
- User-friendly design with plug-and-play compatibility for easy setup and operation.
- Flexible installation with multiple angle adjustment options.
- Supports multiple camera formats for versatile compatibility.
- Weather-resistant build ensures durability for outdoor use in various environments.
- Advanced image processing optimizes picture quality in all scenarios.
- Efficient bandwidth usage allows smooth video transmission without straining the network.
- Reliable surveillance solution ideal for homes, offices, and outdoor premises
| Specification | Details |
|---|---|
| Subseries | D0T-LS Series |
| Available Models | DS-2CE16D0T-LPFS (2.8mm), DS-2CE16D0T-LPFS (3.6mm) |
| Case Type | Bullet |
| Resolution | 2 MP |
| Lens Type | Fixed Lens |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| IR Distance | 21–50 m |
| Focal Length & FOV | 2.8 mm – H: 101°, V: 56°, D: 118°3.6 mm – H: 78°, V: 42°, D: 92° |
| WDR | DWDR |
| Iris Type | 2.8 mm, 3.6 mm fixed focal lens |
| Illumination Level | Normal |
| Lens Mount | M12 |
| Protection Level | IP67 |
| Material | Plastic |
| Supplement Light Type | White Light; IR |
| Supplement Light Range | IR: Up to 25 mWhite Light: Up to 20 m |
| Wide Dynamic Range | Digital WDR |
| Image Enhancement | Yes |
| Image Settings | Brightness, Sharpness, Smart IR |
| Dimension | 138.8 mm × 60.9 mm × 57.9 mm (5.47″ × 2.4″ × 2.3″) |
| Weight | Approx. 155 g (0.34 lb.) |
| Language | English |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F), humidity ≤ 90% (non-condensation) |
| Day & Night | ICR |
| White Balance | Auto/Manual |
| AGC | Yes |
| Consumption | Max. 3.3 W |
| Signal System | PAL/NTSC |
| Day/Night Mode | IR / White Light |
